$820.00
Add to Cart
Keysight E36104B DC Power Supply, 35 V, 1 A, 35 W
2 available
Details
Shipping: US-Mainland: free (more destinations)
Condition: Brand new
Returns: 14 days, buyer pays return shipping (more)
*The store has not been updated recently. You may want to contact the merchant to confirm the availability of the product.
Output rating : 35 W
Voltage: 35 V
Current: 1 A
Power: 35 W
Programming accuracy : ±(% of output + offset)
Voltage: 0.05% + 12 mV
Current: 0.05% + 0.6 mA
Ripple & noise (20 Hz to 20 MHz)
Voltage rms: 1.2 mV
Voltage peak-to-peak: 20 mV
Current rms: 400 µA
Readback accuracy : ±(% of output + offset)
Voltage: 0.05% + 8 mV
Current: 0.05% + 0.5 mA
Keysight E36100B Series basic DC power supplies feature a compact size (2U, ¼-rack), a high-contrast OLED display that is viewable from any angle, and modern USB and LAN (LXI Core) connectivity. Use the highly accurate low-current measure feature for demanding measurements. Protect your DUT with built-in overvoltage and overcurrent protection, and count on the built-in overtemperature protection to keep your power supply safe. Get connected to your instrument quickly via the intuitive front-panel interface, a web interface running on a browser, a SCPI or IVI program, Keysight IO Libraries, or a BenchVue app running on your PC or mobile device. Choose the best model for your needs: five models offer up to 5 A or 100 V.
Clean, reliable power supply
Low, normal mode noise specifications assure quality power for precision circuitry applications enabling you to power your design with confidence
Accurate voltage/current programming and read back capability provides excellent control to precisely power your device under test
Protection for your device under test (DUT) includes overvoltage, overcurrent, and overtemperature protection
Convenient benchtop capabilities
USB and LAN (LXI Core)
BenchVue software support and web interface control
Compact, intuitive package
Save space on your bench, 2U ¼ rack
Easily view the high contrast OLED display
Intuitive on-screen menu
Voltage: 35 V
Current: 1 A
Power: 35 W
Programming accuracy : ±(% of output + offset)
Voltage: 0.05% + 12 mV
Current: 0.05% + 0.6 mA
Ripple & noise (20 Hz to 20 MHz)
Voltage rms: 1.2 mV
Voltage peak-to-peak: 20 mV
Current rms: 400 µA
Readback accuracy : ±(% of output + offset)
Voltage: 0.05% + 8 mV
Current: 0.05% + 0.5 mA
Keysight E36100B Series basic DC power supplies feature a compact size (2U, ¼-rack), a high-contrast OLED display that is viewable from any angle, and modern USB and LAN (LXI Core) connectivity. Use the highly accurate low-current measure feature for demanding measurements. Protect your DUT with built-in overvoltage and overcurrent protection, and count on the built-in overtemperature protection to keep your power supply safe. Get connected to your instrument quickly via the intuitive front-panel interface, a web interface running on a browser, a SCPI or IVI program, Keysight IO Libraries, or a BenchVue app running on your PC or mobile device. Choose the best model for your needs: five models offer up to 5 A or 100 V.
Clean, reliable power supply
Low, normal mode noise specifications assure quality power for precision circuitry applications enabling you to power your design with confidence
Accurate voltage/current programming and read back capability provides excellent control to precisely power your device under test
Protection for your device under test (DUT) includes overvoltage, overcurrent, and overtemperature protection
Convenient benchtop capabilities
USB and LAN (LXI Core)
BenchVue software support and web interface control
Compact, intuitive package
Save space on your bench, 2U ¼ rack
Easily view the high contrast OLED display
Intuitive on-screen menu
